Model 7000 – Incandescent Explosion Proof String Lights

$0.00

5 or 10 Light Head String Work Lights



Download Datasheet (PDF)

Description

Model 7000 Series

Incandescent Explosion Proof String Lights

The Model 7000 Series | Incandescent Explosion Proof String Lights is designed to provide an effective lighting solution for operators requiring a versatile source of illumination. The housing is constructed of aluminum with a rubber bumper guard making it rain tight and weather proof. This hazardous location hand lamp is Class 1, Division 1 approved and equipped with a 100 watt bulb. This explosion proof drop light with optional stringer configurations is ideal for hazardous work areas where a ready source of easily managed lighting is desired.

Click on the “Additional Information” tab for a listing of it’s product features.

Go to our Industries & Applications page to view photo galleries of our lights in use.

Additional information

Approved for:

Class I, Div 1, Groups C & D (100W max)
Class II, Div 1, Groups F & G (75W max)
Class I, Zone 1, Group IIB

Conforms to:

UL E30252

Certified to:

CSA LR39801

UL Temperature Rating:

T3B (160°C)

Rated:

NEMA 4X
NEMA 5-15 (power cord)

Designed to:

NEC Article 500

Features:

Rain tight & weather proof

Bulb Type:

Incandescent- size: A21

Watts:

100W (75W option)

Fixture Lumens:

1,600 lumens (100W)

Fixture Voltage:

250V max
Voltage w/ plug 120V AC
12 Volt available upon request with inline transformer

Material/ Construction:

Non-Sparking Aluminum
Tempered Glass Globe
Rubber Bumpers

Mounting:

Full swivel hook

Configurations:

Model 7000 (Single lighthead)
7000-100-5 (5 lighthead, 100W stringer)
7000-100-10 (10 lighthead, 100W stringer)
